Vocational Car CAN-BUS System Teaching Boar

Vocational Car CAN-BUS System Teaching Boar

Product description

The trainer contains related parts of the car engine piping systems and comfort systems.

Structure and composition

The engine control system, anti-theft system, comfort system control unit, door latch, window regulator, electric mirrors, CAN wiring harness, etc.

Features

1. The working principle of the Comfort CAN bus system and the running of external diagnostic terminal can be displayed the through the original car combination meter and LED.

2. It has the specialized troubleshooting and set areas. The teacher can set multiple faults,.

3. It has the diagnostic connector. the students can test the entire comfort system, CAN data transmission network.

4. Computer detection terminals can be used to detect the voltage signal of the respective terminals which make it easily to analyze the fault.

Technical parameter

1. Nylon caster with locking casters, it can be moved freely for easily teaching

2. Power supply: AC220V, 50Hz

3. Dimensions: about 1260x850x1860mm
