Vocational Intermediate electrician skill training device

Features

The structure of the electric control line components is plank and hanging box. It has PLC inverter, touch screen and other training module, which combined with multiple motors. And it can complete the PLC, inverter, touch screen control training on motor and skills assessment.

Technical parameter

1. Working power: three-phase four wire (or three-phase five wire) ~380V±5% 50Hz; Ã¯Â¼Å“1.5KVA
2. Working temperature: -10℃~40℃, relative humidity＜85%(25℃), altitude<4000m
3. Action current leakage protection:≤30mA
4. The action time of leakage protection:≤0.1s

Training contents

1. Three-phase asynchronous motor directed starting control circle
2. Three-phase asynchronous motor electric control circuit
3. Three-phase asynchronous motor self-locking control circuit
4. Three-phase asynchronous motor forward and reverse control circuit
5. Three-phase asynchronous motor reversing contactor interlock control circuit
6. Dual-phase asynchronous motor reversing control interlock circuit
7. Three-phase asynchronous motor control circuit round the table automatically
8. Two-phase asynchronous motor starting and stopped sequence control circuit.
9. The two-phase asynchronous motor control circuit
10. Contactor control Y-â–³
11.Time relay control Y-â–³
12.The three-phase asynchronous motor unidirectional starting braking control circuit
13.Three-phase asynchronous motor without half-wave rectifier transformer dynamic braking control
14.Three-phase asynchronous motor has full-wave rectifier transformer dynamic braking control
15.Three-phase asynchronous motor start reversing the brake control circuit power consumption
16.Single-phase squirrel cage motor control circuit capacitor start
17.Two-speed manual transmission AC induction motor control circuit
18.Two-speed automatic transmission AC induction motor control circuit
19.The power failure delayed the DC dynamic braking of Y-â–³ start control circuit
20.Three-phase asynchronous motor reversing braking control circuit
21.Reverse -phase asynchronous motor start reversing the brake control circuit
22.No.C620 Turning electrical control circuit
23.Electric hoist electric control
24.No.Y3150 Hobbing machine control circuit
25.The basic operating instructions of the programmable controller
26.LED digital display control
27.Light-day control tower simulation
28.Analog crossroads traffic lights
29.Simulated robot action
30.Simulation of four conveyor belt
31.Simulation of assembly line control
32.Simulation of five phase stepper motor control
33.Simulation of the water level analog control
34.Analog quasi-liquid mixing index analog control
35.Simulation of analog mail sorting machine control
36.Simulation of rolling steel machine analog control
37.Simulation of automatic molding machine control
38.Simulation of automatic Feeding loading control
39.Simulation of automatic washing machine control
40.Similation of plating production line control
41.PLC controlled three-phase asynchronous motor reversing control
42. PLC controlled three-phase asynchronous motor Y-â–³ starting control
43. PLC controlled three-phase asynchronous electric start control buck
44.PLC-controlled three-phase asynchronous electric brake control energy consumption
45.The installation and operation of the converter function parameters
46.Inverter alarm and protection function
47.Multi speed selection of variable frequency speed governing
48.The external terminals of electric control
49.Reversing motor control motion control
50. Running time motor control operation
51.Momentary power inverter parameter settings
52. External voltage frequency control
53. External current inverter
54.The frequency of the three-phase asynchronous motor open loop speed control
55.PLC control inverter
